| Voltage | 12V |
| Amperage | 240A |
| Mount Leg ID | 65mm |
| C-C Mounts | 160mm |
| Hole ID Top | 10mm |
| Hole ID Bottom | 10mm |
| Shaft Size | 17mm |
| Pulley Type | 9PV, FIXED |
| Pulley Belt Width | |
| Pulley Grooves | 9 |
| Pulley Diameter | 55mm |
| Regulator Type | INTERNAL |
| Series | |
| Connections Plug # | EP35 |
| Terminals | B+, S, IG, L, M(FR) |
| Excitation | EXTERNAL |
| Ground |
NEGATIVE |
NOTE:
PLEASE NOTE A BATTERY POSITIVE WIRING UPGRADE IS NEEDED FOR THIS ALTERNATOR.
