| Voltage | 12V |
| Amperage | 110A Hot (96c) 126A Cold (40c) |
| Mount Leg ID | 76mm |
| C-C Mounts | 168mm |
| Hole ID Top | 3/8 UNC |
| Hole ID Bottom | 11mm |
| Shaft Size | 17mm |
| Pulley Type | SINGLE "A" |
| Pulley Belt Width | |
| Pulley Grooves | 1 |
| Pulley Diameter | 82mm |
| Regulator Type | INTERNAL |
| Series | K1 |
| Connections Plug # | |
| Terminals | B+, D+, W |
| Excitation | EXTERNAL |
| Ground |
NEGATIVe |
4 Phase Stator Rectifier
NSK Bearings
Anti Vibtaion Protection
