| Voltage | 12V |
| Amperage | 240A |
| Mount Leg ID | 51mm |
| C-C Mounts | 139mm |
| Hole ID Top | 10mm |
| Hole ID Bottom | 10mm |
| Shaft Size | 17mm |
| Pulley Type | 6PV, CLUTCH |
| Pulley Belt Width | |
| Pulley Grooves | 6 |
| Pulley Diameter | 51mm |
| Regulator Type | INTERNAL |
| Series | |
| Connections Plug # | EP56-2 |
| Terminals | B+, F(DFM), L(RVC) |
| Excitation | EXTERNAL |
| Ground | NEGATIVE |
| Weight (Kg) | 9.0kg |
